FI-AMP300DSP
4 channel bridgeable class D power amplifier, 4 x 300W @ 8Ω
The FI-AMP300DSP is a state of the art 4 channel Class D amplifier include comprehensive signal processing providing 300 Watts per channel at 8Ω. It provides 4 x front panel access volume control allowing zone level adjustments directly from the Amplifier. The FI-AMP300DSP is designed for use in a wide variety of installations: from a simple setup in a bar/ restaurant or a corporate meeting room to being a part of a larger audio system in a theater. Pairs of channels may be individually configured to run in Stereo, Parallel or Bridged mode
Features
Applications
Specifications
- Includes comprehensive signal processing
- Lightweight portable 1U ultra-thin design with 4 channels
- 300 Watts per channel at 8Ω
- Intuitive, user-friendly, front panel interface
- Four channel separate balanced line inputs by XLR Female
- Four Speakon (4 contacts) output connectors
- Very high power density in 1U rack height
- Four channel separate volume control
- Comprehensive protection and monitoring functions
- Four channel separate status indicators include signal, peak and protection
- Amplifier with delay start system, protect the speakers from shock and damage
- Class-D design for optimum efficiency
- Superior sound quality performance
- From bars, restaurants, retail stores, church to corporate meeting rooms and auditoriums
- Sound reinforcement applications with mid power density and good sounding requirements
- Portable or rental industry PA system
| Specification | |
| Outputs | @ 8Ω 4 x 300 W @ 4Ω 8 x 600 W Bridged 2X1200W@ 8Ω |
| Inputs | 4 x XLR (Bal.) |
| Working Voltage | 90V-264V, 50-60Hz |
| Input sensitivity | 0.775V\1V\1.44V(Switch Selectable) |
| Frequency response | 20 Hz to 20 KHz (+/-0.5dB)@1W, 8Ω |
| THD + N | <-0.08% from 0.1W to 1/2 power |
| DIM100 | < 0.2% from 0.1W to 1/2 power |
| S/N Ratio | >100 dB（20Hz-20Khz, A weighted） |
| Channel separation | > -80dB @ 8 Ω / 1 KHz |
| Input impedance | 4.5 KΩ (Bal.) |
| Controls | |
| Front | On/ Off Switch, 4 x Volume Ctl. |
| Rear | Ground lift, Input link mode, Bridge mode (pair) |
| Input connectors | 4 x XLR (Bal.) |
| Ouput connectors | 4 x Speakon 4 contacts (1+/1- 2+/2-) |
| Dimention | 483*290*44,45mm |
| Weight | 6 Kg - 13.1 Lbs |
