FI-CT8
8-inch Full Range Coaxial Speaker
FI-CT8 is a trapezoidal built-in two-way coaxial 8-inch full-range speaker. The speaker uses a 1-inch titanium diaphragm compressor driver and an 8-inch low frequency driver, suitable as a near-field speaker.
The ttanium diaphragm tweeter provides a crisp high frequency and a high-powered low distorton. With the coaxial structure design, it solves the common problem of poor trans- mission of conventonal single speaker unit, therefore having a very balanced near-field tone. Aluminum horn and paper woofer combine to form a near-field, wide-angle exponental tweeter horn with a coverage angle of 80 (H)×80°(V).
Features
Applications
Specifications
- Exquisite appearance
- Ultra-wide frequency response coverage
- Ultra-wide pointing angle
- Optimize frequency divider and unit structure to effectively eliminate phase interference
- Lecture hall, conference room, fill speakers, foldback monitor
| Acoustic parameters | |
| Frequency range | 91 Hz - 20 kHz (-10 dB) |
| SPL 1W/1mt | 93 (±2) dB |
| Rated Power(W) | 250W ( AES ) |
| Rated Impedance (Ω) | 8 ohms |
| Maximum sound pressure level (S P L) | 116dB (contnuous), 122dB (peak) |
| Coverage | |
| Nominal coverage angle (H x V) | 80°×80° |
| Speaker unit | |
| Woofer | Ferrite, 1 x 8”woofer/50mm voice coil |
| Tweeter | Ferrite, 1 x 1" port tweeter/44mm voice coil |
| Physical properties | |
| Hanging parts | 10×M8 lifting point, bottom support |
| Connections | Two professional NL4MP four-core sockets, 1+1-full frequency input |
| Product weight( k g ) | 8( kg ) |
| Dimension ( W×D×H ) | 245×270×320（mm） |
