FI-SMS6(PRO)
Two-way surface mounted speaker with two radiator
The elegant design allows the FI-SMS6(PRO) to be used for any installations and environment, keeping the same high quality sound throughout.
The FI-SMS6(PRO), made of ABS with a front metal grille, utilizes a compact two-way system (6” woofer, 1” tweeter and two passive radiator) guaranteeing high performances, wide dynamics, high fidelity sound reproduction and high voice intelligibility.
Multi-position, C-shaped mounting bracket and rugged construction provide optimum installation flexibility and assurance of long-term service.
Its power tap selector makes it suitable for high (70V/100V) voltage line and low impedance (8Ω). This surface mounting speaker is designed to offer an economic and professional solution to contractors.
- Two-way speaker with rich sonic character
- Two passive radiator for ultimate low frequency response
- Wide and consistent coverage
- Suitable for high (70/100 V) voltage line and low impedance (8Ω) installations
- Contemporary, high-design appearance
- High fidelity sound character with broad frequency response of 50 Hz - 20 kHz.
- High quality speaker enclosures made of strong ABS material
- Heavy-duty C-bracket for mounting included
- Easy installation
- Waterproof grade IPX56
- The FI-SMS6(PRO) is an excellent choice for a wide variety of applications, including retail stores, restaurants, health clubs, theme parks, educational facilities, hospitality, music cafes, leisure venues, and anywhere where a top quality high-output indoor/ outdoor foreground/ background music(and/or paging) speaker is required.
| General Specification | |
| type | FI-SMS6 (B/W) |
| Frequency response | 70 -20 KHz |
| Sensitivity | 90dB @ 1 watt / 1 meter |
| Power Handling | 60 W |
| Power taps | 60W/30W/15W/7.5W & 8Ω |
| Line input | 100 V / 70 V |
| Dimension (L x W x H) (mm) | 214*178*329 |
| Physical Specification | |
| Material (panel) | HIPS |
| Grille | Powder Coated AL Mesh |
| Component (L.Speaker) | 6.5 inch Woofer |
| Component (H.Speaker) | 1 inch silk |
| Finished Colour | White/Black |
| Unit Weight | 4.76 Kg |
| Woofer Speaker Specification | |
| Voice Coil Size | ASVø25.5*ø 0.19*2Layer |
| DC Impedance | 6.8Ω |
| Former | ASV |
| Magnet | Ferrite (400g) ø 90*ø 32*15(Y30) |
| Basket | Iron |
| Cone Material | Paper |
| Spider | Conex |
| Dust cap | Paper |
| Net Weight | 1.1kg |
