FS4X3

46 cm Passive Array (4 x 3.25")

The FS4X3 Array features four 3.25’’ mid/high frequency drivers.

FS4X3 Array delivers 90 degrees of horizontal coverage and 10 degrees vertical coverage.

The compact line array guarantees high performance in a unique and flexible design.

It is unbelievably easy to use and it delivers a perfect sound quality.

Sleek and lightweight, its shape has been designed specially for invisible audio installation.

Features Applications Specifications
  • Compact Plug and Play line array
  • Discreet look for inconspicuous use
  • Line array element configuration (4 x 3,25” speakers) offers exceptional sound coverage
  • Compact speaker line array for concerts, conferences and events and more
  • Delivers 90° of horizontal coverage and 10° vertical coverage with and a very long acoustic throw capacity
  • Designed, engineered and tuned in Italy
  • The FS4X3 array is ideal for mobile and installed applications
  • A good solution for all sizes of indoor/outdoor live event and applications such as large restaurant, lounge, bar,
    conference, school auditorium and places of worship
Comprehensive parameters
Frequency Response 150 Hz - 19000 Hz
SPL 1W@1mt 93dB
Maximum SPL 115dB (cont.) - 121dB (peak)
Number of Drivers 4
Driver size 3.25”
Rated Power 120W
Impedance
Connector Speakon
Number of Connector 1in
Coverage
Horizontal 90°
Vectical 15°
Physical Parameters
Dimensions (W x H x L) 9,0 cm x 46,0 cm x 11,3 cm
Weight 9 kg
