Slimline array speaker systemsPerformance

FS4X3

46 cm Passive Array (4 x 3.25")

The FS4X3 Array features four 3.25’’ mid/high frequency drivers.

FS4X3 Array delivers 90 degrees of horizontal coverage and 10 degrees vertical coverage.

The compact line array guarantees high performance in a unique and flexible design.

It is unbelievably easy to use and it delivers a perfect sound quality.

Sleek and lightweight, its shape has been designed specially for invisible audio installation.

Features

  • Compact Plug and Play line array
  • Discreet look for inconspicuous use
  • Line array element configuration (4 x 3,25” speakers) offers exceptional sound coverage
  • Compact speaker line array for concerts, conferences and events and more
  • Delivers 90° of horizontal coverage and 10° vertical coverage with and a very long acoustic throw capacity
  • Designed, engineered and tuned in Italy

Applications

  • The FS4X3 array is ideal for mobile and installed applications
  • A good solution for all sizes of indoor/outdoor live event and applications such as large restaurant, lounge, bar,
    conference, school auditorium and places of worship

Specifications

Comprehensive parameters
Frequency Response150 Hz - 19000 Hz
SPL 1W@1mt93dB
Maximum SPL115dB (cont.) - 121dB (peak)
Number of Drivers4
Driver size3.25”
Rated Power120W
Impedance4Ω
ConnectorSpeakon
Number of Connector1in
Coverage
Horizontal90°
Vertical15°
Physical Parameters
Dimensions (W x H x L)9,0 cm x 46,0 cm x 11,3 cm
Weight9 kg
